Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
non return valve (pressure-resistant up to 2 MPa)92594000
2
non return valve97980000
3
noise reduction94073000
4
O-ring 16x298133000
5
O-ring 36x298156000
6
set of screws96525000
7
shut off unit95758000
8
nut98368000
9
Select-adapter92219000
10
thermostat cartridge98282000
11
O-ring 20x1,598197000
12
O-ring 25x1,598146000
13
O-ring 25x2,592146000
14
nut98913000
15
holder for escutcheon98793000
16
set of fixing screws96454000
17
set of symbols92544610
18
escutcheon 170 / 170 mm92637001
19
O-ring 48x498414000
20
adapter for handle98701000
21
handle for thermostat92534000
22
sleeve92216000
23
nut and flange92696000
24
fit-up aid92540000
25
extension 22 mm97407000
26
extension 25 mm13595000
