AXOR MontreuxHighArc Kitchen Faucet 2-Spray Pull-Down, 1.75 GPM
Model no. 16581001
Please try again.
Article features
- Swivel range 110° / 150°
- Laminar spray, needle spray
- Toggle spray diverter
- MagFit magnetic sprayhead docking
- Deck mounted
- Flow: 1.75 GPM (6.6 L/Min)
- Ceramic cartridge
- ⅜" connections
- Integrated double backflow prevention
- Extension length up to 19 5/8” (50cm)
Download Center
Planning data
BIM data
Technical drawings
Instructions
Spare parts for build year 01/18
| Item no. |
|---|
| 1 | spout cpl.92972000 |
| 2 | filter97735000 |
| 3 | set of non return valves DW 1597350000 |
| 4 | O-ring 18x1,598231000 |
| 5 | aerator laminar M22x1 (15 l/min)95909000 |
| 6 | O-ring 20x198140000 |
| 7 | handle92963000 |
| 8 | cover cap92964000 |
| 9 | O-ring 16x298133000 |
| 10 | hollow set screw M6x898444000 |
| 11 | screw cover96762000 |
| 12 | flange92965000 |
| 13 | nut92966000 |
| 14 | O-ring 33x1,598164000 |
| 15 | cartridge, assy92730000 |
| 16 | seal95008000 |
| 17 | O-ring 8x1,7597827000 |
| 18 | connection hose 600 mm M10x195561000 |
| 19 | hose 1,50 m88624000 |
| 20 | weight92500000 |
| 21 | fixing set (Ø 34)95049000 |
| 22 | lever collar97548000 |
| 23 | support97523000 |
| 24 | seal92582000 |
| 25 | connection hose 35½" M8x0,75 3/8"96316001 |
| 26 | handspray92967001 |
| 27 | non return valve93218000 |
| 28 | service tool95910000 |
Innovative technologies
Saving resources with pleasure
Flexibility at the kitchen sink
QuickClean: Less limescale, more pleasure
EcoRight
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
Pull-out
Flexibility at the kitchen sink
More comfort and room to move: Pull-out sprays or pull-out spouts expand the operating radius around the kitchen sink to take water to exactly where it’s needed in just one motion.
QuickClean
QuickClean: Less limescale, more pleasure
Who likes cleaning? Limescale deposits and dirt disappear in an instant. You can rub off the flexible silicone lamellae or nubs with your finger. This takes no time at all and minimises the cleaning effort.
Spray Types
Manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
