hansgrohe Talis SPrep Kitchen Faucet, 2-Spray Pull-Down, 1.75 GPM

Model no. 72815001
Please try again.
Article features
- Swivel range 110° / 150°
- Laminar spray, needle spray
- Toggle spray diverter
- MagFit magnetic sprayhead docking
- Deck mounted
- Flow: 1.75 GPM (6.6 L/Min)
- Ceramic cartridge
- ⅜" connections
- Integrated double backflow prevention
Download Center
Installation information
Scale drawing
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Spare parts for build year 02/21
To the spare parts catalogItem no. | DescriptionArticle no.Description and article no. |
---|
1 | handle93148000 |
2 | hollow set screw M6x10 DIN 91696029000 |
3 | screw cover95704000 |
4 | flange95493000 |
5 | nut98864000 |
6 | O-ring 23x298398000 |
7 | O-ring 27x1,592527000 |
8 | O-ring 25x1,598146000 |
9 | cartridge, assy97685000 |
10 | seal98865000 |
11 | spout cpl.93159000 |
12 | set of lever collars98365000 |
13 | O-ring 21x2,598211000 |
14 | hose 1,25 m95506000 |
15 | O-ring 11x298127000 |
16 | filter97735000 |
17 | handspray92732000 |
18 | non return valve93218000 |
20 | aerator laminar M22x1 (15 l/min)95909000 |
21 | O-ring 20x198140000 |
22 | service tool95910000 |
23 | support97523000 |
24 | fixing set (Ø 34)95049000 |
25 | lever collar97548000 |
26 | weight98551000 |
27 | connection hose 600 mm M10x195561000 |
28 | O-ring 8x1,7597827000 |
29 | connection hose 35½" M8x0,75 3/8"96316001 |
30 | O-ring 7x1,598422000 |
Innovative technologies
Saving resources with pleasure
For more space at the kitchen sink
Flexibility at the kitchen sink
QuickClean: Less limescale, more pleasure
EcoRight
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
ComfortZone
For more space at the kitchen sink
Used to describe the generous space created between the kitchen tap and the sink - vertically and horizontally. These high-quality taps are highly user-friendly and have a flexible swivel range. For maximum freedom of movement.
Pull-out
Flexibility at the kitchen sink
More comfort and room to move: Pull-out sprays or pull-out spouts expand the operating radius around the kitchen sink to take water to exactly where it’s needed in just one motion.
QuickClean
QuickClean: Less limescale, more pleasure
Who likes cleaning? Limescale deposits and dirt disappear in an instant. You can rub off the flexible silicone lamellae or nubs with your finger. This takes no time at all and minimises the cleaning effort.
Spray Types


LaminarSpray
Crystal-clear spray type with no added air for the sink. This spray is a great help when going through the day-to-day kitchen routine, e.g. quickly filling large pots or bowls. Efficient with very little splashback.

ShowerSpray
Resource-saving shower spray at the sink. Whether fruit or vegetables, fish or meat, the soft spray helps to gently yet efficiently clean food and other items.

Manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
