hansgrohe Aquno SelectHighArc Kitchen Faucet, 3-Spray Pull-Down, 1.75 GPM
Model no. 73837001
Please try again.
Article features
- Swivel range adjustable in 3 steps: 60°, 110° or 150°
- Laminar spray, needle spray, SatinFlow
- Change between SatinFlow and pull-out sprayer at the touch of a button
- Toggle spray diverter
- MagFit magnetic sprayhead docking
- Deck mounted
- Flow: 1.75 GPM (6.6 L/Min)
- Ceramic cartridge
- ⅜" connections
- Integrated double backflow prevention
- Extension length up to 19 5/8” (50cm)
- Recommendation: the middle of tap hole drilling should be max. 1.96" from the back side of of the bowl
Download Center
Planning data
Technical drawings
Instructions
Certificates
Spare parts for build year 04/20
| Item no. |
|---|
| 1 | set of lever collars98365000 |
| 2 | O-ring 19x298426000 |
| 3 | handspray93778001 |
| 4 | non return valve DW 1096456000 |
| 5 | spray former93342001 |
| 6 | service tool95910000 |
| 7 | spray head cpl.93781000 |
| 8 | O-ring 10x298170000 |
| 9 | handle93776000 |
| 10 | nut92926000 |
| 11 | cartridge, assy93183000 |
| 12 | cover93777000 |
| 13 | spring with sleeve93782000 |
| 14 | selector assy93558000 |
| 15 | hose93745000 |
| 16 | O-ring 8x298112000 |
| 17 | null92914000 |
| 18 | O-ring 8x1,7597827000 |
| 19 | connection hose 900 mm M10x1 G3/893780000 |
| 20 | adapter for connection hose88802000 |
| 21 | spout cpl.93779000 |
| 22 | fixing set (Ø 34)95049000 |
| 23 | lever collar97548000 |
| 24 | support97523000 |
| 25 | weight92500000 |
Innovative technologies
Saving resources with pleasure
Convenience at the touch of a button
For more space at the kitchen sink
Flexibility at the kitchen sink
QuickClean: Less limescale, more pleasure
EcoRight
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
Select
Convenience at the touch of a button
Fans of user-friendliness can now conveniently start and stop the flow of water at the touch of a button. For accurate, ergonomic and easy water controls that can be operated with the back of the hand or an elbow.
ComfortZone
For more space at the kitchen sink
Used to describe the generous space created between the kitchen tap and the sink - vertically and horizontally. These high-quality taps are highly user-friendly and have a flexible swivel range. For maximum freedom of movement.
Pull-out
Flexibility at the kitchen sink
More comfort and room to move: Pull-out sprays or pull-out spouts expand the operating radius around the kitchen sink to take water to exactly where it’s needed in just one motion.
QuickClean
QuickClean: Less limescale, more pleasure
Who likes cleaning? Limescale deposits and dirt disappear in an instant. You can rub off the flexible silicone lamellae or nubs with your finger. This takes no time at all and minimises the cleaning effort.
Spray Types
