AXOR Citterio ESingle-Hole Faucet 250 with Lever Handle, 1.2 GPM, without Drain
Model no. 36113001
Please try again.
Article features
- Handle variant: Lever
- Spray modes: Laminar spray
- Flow: 1.2 GPM (4.5 L/Min)
- Ceramic cartridge
Download Center
Certificates
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Spare parts for build year 07/16
To the spare parts catalogItem no. | DescriptionArticle no.Description and article no. |
---|
1 | handle92593000 |
2 | screw cover96762000 |
3 | flange98863000 |
4 | nut98864000 |
5 | O-Ring 22x298185000 |
6 | O-ring 28x1,598421000 |
7 | O-ring 25x1,598146000 |
8 | cartridge, assy95973001 |
9 | seal98865000 |
10 | adapter for cartridge98866000 |
11 | O-ring 23x298398000 |
12 | aerator laminar M16,5x1 (4,5 l/min)92876000 |
13 | special tool98987000 |
14 | O-ring 30x1,598433000 |
15 | escutcheon92190000 |
16 | fixing set (Ø 32)13961000 |
17 | lever collar97548000 |
18 | connection hose 35½" M8x0,75 3/8"96316001 |
Innovative technologies
Excellent user comfort
Saving resources with pleasure
ComfortZone
Excellent user comfort
Greater freedom of movement when washing hands and hair or filling containers: The more precise the fit of the tap, the greater the convenience in the daily use of water. We call this individual use space between the tap and the ceramics the ComfortZone.
EcoRight
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
Manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
