AXOR Citterio M
Diverter Trim Trio/Quattro

product.image.alt
 View in AR
 360° view
Finish chrome

Model no. 34934001

Article features

  • Handle, sleeve, Metal escutcheon

Download Center

Planning data

Download all Planning data files

Technical drawings

Download all Technical drawings files

Instructions

Download all files

Certificates

Minimum Advertised Price (MAP)

cUPC® Listed

 cUPC® Listed products comply with applicable sections of the Uniform Plumbing Code (UPC®), National Plumbing Code of Canada, and International Plumbing Code (IPC®), as well as applicable sections of IAPMO Z124.1.2-2005 / CSA B45.5-2002

Installation information

Scale drawing

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.

Required parts - Select variant

Rough, Trio 2-Way Diverter without Shut-Off, ¾"
hansgrohe

Rough, Trio 2-Way Diverter without Shut-Off, ¾"
Rough, Quattro Green 3-Way Diverter (no shared function), ¾"
hansgrohe

Rough, Quattro Green 3-Way Diverter (no shared function), ¾"
Rough, Trio 2-Way Diverter with Shut-Off, ¾"
hansgrohe

Rough, Trio 2-Way Diverter with Shut-Off, ¾"
Rough, Quattro 3-Way Diverter, ¾"
hansgrohe

Rough, Quattro 3-Way Diverter, ¾"

Spare parts for build year 06/09

To the spare parts catalog
To the spare parts catalog
product.spareparts.image.alt
Item no. DescriptionArticle no.Description and article no.
b base body15930181
d base body15984181
c base body15936181
e base body15981181
a extension 25 mm96370000
1 handle38993001
2 handle fixing set94184001
3 cover cap96541001
4 nut96489000
5 escutcheon98963000
6 seal97737000
7 set of symbols95238000
8 O-ring 13x298128000
9 fixing set96392000
