AXOR UrquiolaWidespread Faucet 50 with Pop-Up Drain, 1.2 GPM
Model no. 11041001
Please try again.
Article features
- Handle variant: Lever
- Spray modes: normal spray
- Flow: 1.2 GPM (4.5 L/Min)
- Ceramic valves hot/cold 90°
- Includes pop-up drain
Download Center
Technical drawings
Instructions
Certificates
Spare parts for build year 07/16
| Item no. |
|---|
| a | pop up waste94159000 |
| 1 | handle for hot water95304000 |
| 2 | handle for cold water95305000 |
| 3 | handle fixing set98932000 |
| 4 | escutcheon95307000 |
| 5 | shut off unit left closing94008000 |
| 6 | aerator M24x1 (4,5 l/min)92877000 |
| 7 | spout cpl.95303000 |
| 8 | pull rod96923000 |
| 9 | fixing set (Ø 32)13961000 |
| 10 | connection hose 18½" M8x0,75 3/8"96321001 |
| 11 | O-ring 34x498155000 |
| 12 | flat seal98749000 |
| 13 | O-ring 13x298128000 |
| 14 | shut off unit right closing94009000 |
| 15 | fixation extension 35 mm13898000 |
Innovative technologies
Excellent user comfort
Saving resources with pleasure
QuickClean: Less limescale, more pleasure
ComfortZone
Excellent user comfort
Greater freedom of movement when washing hands and hair or filling containers: The more precise the fit of the tap, the greater the convenience in the daily use of water. We call this individual use space between the tap and the ceramics the ComfortZone.
EcoRight
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
QuickClean
QuickClean: Less limescale, more pleasure
Who likes cleaning? Limescale deposits and dirt disappear in an instant. You can rub off the flexible silicone lamellae or nubs with your finger. This takes no time at all and minimises the cleaning effort.
Manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
