hansgrohe MetrisSingle-Hole Faucet 110 with Pop-Up Drain, 1.2 GPM

Model no. 31080001
Please try again.
Article features
- Handle variant: Lever
- Spray modes: aerated spray
- Flow: 1.2 GPM (4.5 L/Min)
- Ceramic cartridge
- Includes pop-up drain
Download Center
BIM data
Technical drawings
Certificates


Installation information
Scale drawing
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Spare parts for build year 07/16
To the spare parts catalogItem no. | DescriptionArticle no.Description and article no. |
---|
b | aerator M24x1 (3,5 l/min)92508000 |
d | aerator swivelling M24x1 (5 l/min)95928000 |
a | pop up waste88509000 |
c | aerator M24x1 (5 l/min)13185000 |
1 | handle95519000 |
2 | screw cover96338000 |
3 | flange97406000 |
4 | nut97209000 |
5 | cartridge, assy95646001 |
6 | locking screw for handle95140000 |
7 | seal95008000 |
8 | adapter for cartridge98750000 |
9 | aerator M24x1 (4,5 l/min)92877000 |
10 | fixing set (Ø 32)13961000 |
11 | flat seal98749000 |
12 | connection hose 18½" M8x0,75 3/8"96321001 |
13 | pull rod96657000 |
14 | O-Ring 32x298193000 |
15 | O-Ring 30x298186000 |
Innovative technologies
Excellent user comfort
Saving resources with pleasure
QuickClean: Less limescale, more pleasure
ComfortZone
Excellent user comfort
Greater freedom of movement when washing hands and hair or filling containers: The more precise the fit of the tap, the greater the convenience in the daily use of water. We call this individual use space between the tap and the ceramics the ComfortZone.
EcoRight
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
QuickClean
QuickClean: Less limescale, more pleasure
Who likes cleaning? Limescale deposits and dirt disappear in an instant. You can rub off the flexible silicone lamellae or nubs with your finger. This takes no time at all and minimises the cleaning effort.
Manufacturer’s guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
